1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
-
1
Input second，output forth space ring
-
2
Second gear needle bearing
-
3
Second gear second driven gear
-
4
Second gear second driven gear
-
5
Third driven gear
-
6
Output third position sleeve
-
7
Forth driven gear
-
8
Fifth driven gear
-
9
Output fifth circlip
-
10
Output shaft rear bearing
-
11
Output shaft spring washer
-
12
Output shaft spring washer
-
13
Second gear synchronize circlip
-
14
Synchronizer inner ring，1st-2nd speed
-
15
Synchronizer inner ring，1st-2nd speed
-
16
Synchronizer middle ring，1st-2nd speed
-
17
Synchronizer middle ring，1st-2nd speed
-
18
Synchronizer inner ring，1st-2nd speed
-
19
Synchronizer inner ring，1st-2nd speed
-
20
First second synchronize assy.
-
21
First second synchronize assy.
-
22
First driven gear
-
23
First driven gear
-
24
First needle bearing
-
25
Output shaft front bearing
-
26
First synchronize rim
-
27
Вал вторичный 1.6
-
28
Output shaft
-
29
Second gear synchronize rim
