1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
-
1
Fr brg-counter shaft(instruction car)
-
2
Intermediate plate
-
3
Input shaft sub assy
-
4
Transmission
-
5
Output shaft sub assy
-
6
Retainer-output shaft rr bearing(instrus
-
7
Allenscrew
-
8
Retainer ring-counter shaft fr brg(instr
-
9
Thrust washer-counter shaft(instruction
-
10
5th gear sub assy-counter shaft
-
11
Synchronizer key-5th gear(instrustion ca
-
12
Needle roller bearing
-
13
Thrust washer-5th gear(instrustion car)
-
14
Snap ring-counter shaft rr brg(instructi
-
15
Rr brg-counter shaft(instruction car)
-
16
Counter shaft
-
17
Steel ball
-
18
Synchronizer ring-3rd 4th 5th gear(instr
-
19
Conn gear-5th gear(instrustion car)
-
20
Rr retainer ring-counter shaft(instructi
-
21
Shaft-reverse idle gear(instrustion car)
-
22
Reverse idle gear kit
-
23
Fix plate-reverse gear shaft(instrustion
-
24
Fix plate-reverse gear shaft(instrustion
-
25
Gear hub-5th synchronizer(instrustion ca
-
26
Synchronizer retainer ring-3rd 4th 5th g
-
27
Hex bolt w/washer
-
28
Screw
-
29
Retainer ring-5th gear synchronizer
