1
Trans case assy H3145A1701220
-
2
Input shaft assy H3145A1701310
-
3
Output shaft assy H3145A1701400
-
4
Diff assy H3145A2303200
-
5
Magnetic piece H3145A1701253
-
6
Detail H3145A1702260
-
7
Adj shim-input/output shaft H3145A1701371
-
8
Hex bolt H3145A1701251
-
9
Brkt assy-reverse arm H3145A1702290
-
10
Shifting fork rail assy-3rd 4th 5th gear H3145A1702270
-
11
Shifting fork shaft assy-1st 2nd gear H3145A1702265
-
12
Wire clamp??8.5 H3145A1701261
-
13
Gear lever w/select rod assy H3145A1702200
-
14
Small return sprg-gear lever H3145A1702259
-
15
Clutch housing assy H3145A1701130
-
16
Plug cover(square) H3145A1602205
-
17
Reverse idle gear assy H3145A1701610
-
18
Idle gear shaft H3145A1701613
-
19
Bolt-idle gear shaft H3145A1701256
-
20
Brkt-clutch cable H3145A1602234
-
21
Bulb-reverse lamp H3145A1701260
-
22
Hex bolt w/flange reverse brkt H3145A1702295
