1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
-
1
Drive&driven bevel gear assy 2302130K85
-
2
Adj washer-drive bevel gear 2402029D01
-
3
Oil drain plug(4wd fr diff) 2301105K01
-
4
Planet gear shaft 2403016D01
-
5
Planet gear 2403014D01
-
6
Washer-planet gear 2403015D01
-
7
Gear-axle shaft 2303101K85
-
8
Gear thtust washer axle shaft 2403013D01
-
9
Болт шестигранный Q184U1025TFDE
-
10
Large bearing-drive bevel gear fr axle) 32307BC
-
11
Bolt-drive bevel gear 2302101K85
-
12
Fr axle main gear & dustproof shield ass 2302120K01
-
13
Oil seal(fr axle drive bevel gear) 2302130K01
-
14
Oil seal(cold place export fr drive) 2302130K01B1
-
15
Oil baffle disc-drive bevel gear oil sea 2402023D01
-
16
Small bearing-drive bevel gear 30306C
-
17
Spacing sleeve 2302102K85
-
18
Differential adj shim reducer housing 2303103K85
-
19
Bearing 32009W
-
20
Diff housing 2403011D01
-
21
Differential adj shim reducer housing 2303102K85
-
22
Bolt-driven bevel gear 2302103K85
-
23
Oil filler plug 2402402M18
-
24
Return sprg 2302120XK85XB
-
25
Drive&driven bevel gear assy 2302130K85
-
26
Return sprg 2302120XK85XB
